Heavy Duty GEM Oil Sandwich Plate (Filter Adapter Upgrade) with filter

HD VTEC CONVERSION SANDWICH PLATE

Designed to accept a larger filter which has two key benefits;

1) More filter area means more excellent dirt holding capacity and, therefore, greater filtered flow for extended periods before filter media saturation.

2) More oil capacity in the system helps extend the oil's useful life and keep temperatures down.

3) This product is a perfect upgrade for those who already have the Golden Eagle vtec kit.

OPTION GVCHD101

The option contains 1 each of:

- Oil Sandwich Plate Housing, Center Shaft & O-Ring

- Extended Life Oil Filter, Canister, 13/16-16 in. Thread, 5.120 in.

-1/8" Pipe Flush Plug for the -1/8" NPT ( pipe ) port.

-3/4 Boss x 6AN Fitting for the - ( 3/4 Boss ) port

-Head x 6AN Fitting for the V-TEC Head Feed

Note:  V-TEC Hose, Head Dowels & Tap not included

OPTION GVCFULLKIT-NG

The option contains 1 each of:

- Oil Sandwich Plate Housing, Center Shaft & O-Ring

- Extended Life Oil Filter, Canister, 13/16-16 in. Thread, 5.120 in.

-1/8" Pipe Flush Plug for the -1/8" NPT ( pipe ) port.

-3/4 Boss x 6AN Fitting for the - ( 3/4 Boss ) port

-Head x 6AN Fitting for the V-TEC Head Feed

-6AN Braided Steel Hose

- Head Dowel x 2

 Note:  V-TEC Gasket Not Included

OPTION GVCHD100-P

The option contains 1 each of:

- Oil Sandwich Plate Housing, Center Shaft & O-Ring

- Extended Life Oil Filter, Canister, 13/16-16 in. Thread, 5.120 in.

-1/8" Pipe Flush Plug

-1/8" NPT ( pipe ) port

-( 3/4 Boss ) port that will accept numerous fittings.

Note:  AN fittings, V-TEC Hose, Head Dowels & Tap not included

 General Description:

Works with existing oil cooler set-ups and installs in less than 10 minutes.

Can be tailored to add fittings, plugs, etc., to accommodate any customer's needs.

The sandwich plate has two ( 2 ) ports.

-1/8" NPT ( pipe ) port

- 3/4 boss port that will accept numerous fittings.
